This is to go over a container image pipeline that will scan for vulnerabilities and generate a Software Bill of Materials at the end.

Proposed Architecture

graph TD
    A[Dev User Pushes Dockerfile to git repo] -->|git repo notifies Jenkins| B(Jenkins pulls down repo and kicks off job) -->|Pipeline Builds Docker Image| C(Dependencies are pulled from artifact management system) -->|Trivy runs against the docker image,the FS and the code| D(Jenkins pulls down repo and kicks off job)
    D --> E{Vuln Scan}
    E -->|Passes| F[Docker Image is uploaded to artifact management system]
    F --> G(SBOM gets genrated and uploaded to artifact mangament system)
    E -->|fails| H[pipeline fails and stops]

Trivy

What is Trivy?

Trivy (tri pronounced like trigger, vy pronounced like envy) is a simple and comprehensive scanner for vulnerabilities in container images, file systems, and Git repositories, as well as for configuration issues. Trivy detects vulnerabilities of OS packages (Alpine, RHEL, CentOS, etc.) and language-specific packages (Bundler, Composer, npm, yarn, etc.). In addition, Trivy scans Infrastructure as Code (IaC) files such as Terraform, Dockerfile and Kubernetes, to detect potential configuration issues that expose your deployments to the risk of attack. Trivy also scans hardcoded secrets like passwords, API keys and tokens. Trivy is easy to use. Just install the binary and you’re ready to scan.

Trivy

Features

Comprehensive vulnerability detection
- OS packages (Alpine Linux, Red Hat Universal Base Image, Red Hat Enterprise Linux, CentOS, AlmaLinux, Rocky Linux, CBL-Mariner, Oracle Linux, Debian, Ubuntu, Amazon Linux, openSUSE Leap, SUSE Enterprise Linux, Photon OS and Distroless)
Language-specific packages (Bundler, Composer, Pipenv, Poetry, npm, yarn, Cargo, NuGet, Maven, and Go) Misconfiguration detection (IaC scanning)
- A wide variety of built-in policies are provided out of the box
  - Kubernetes, Docker, Terraform, and more coming soon
- Support custom policies
Secret detection
- A wide variety of built-in rules are provided out of the box
- Support custom rules
- Scan container images at a high speed
Simple
- Specify only an image name, a path to config files, or an artifact name
Fast
- The first scan will finish within 10 seconds (depending on your network). Consequent scans will finish in a single second.
Easy installation
- apt-get install, yum install and brew install are possible.
- No pre-requisites such as installation of DB, libraries, etc.
High accuracy
- Especially Alpine Linux and RHEL/CentOS
- Other OSes are also high
DevSecOps
- Suitable for CI such as GitHub Actions, Jenkins, GitLab CI, etc.
Support multiple targets
- container image, local filesystem, and remote git repository
Supply chain security (SBOM support)
- Support CycloneDX
- Support SPDX

Integrations

VSCode via an extension -https://github.com/aquasecurity/trivy-vscode-extension

Docker Dekstop via an extension - https://github.com/aquasecurity/trivy-docker-extension#:~:text=Trivy%20Docker%20Extension-,What%20is%20this%3F,image%20into%20the%20drop%20down

SBOM’s

Trivy can create a Software Bill of Materials!

For Containers:

>$ trivy sbom <imagename>

For Filesystems:


>$ trivy sbom --artifact-type fs ./

For Git Repos:


>$ trivy sbom --artifact-type repo <repo>

Where does Trivy get its data sources from?

Data sources official doc: https://aquasecurity.github.io/trivy/v0.28.1/docs/vulnerability/detection/data-source/

OS

OS	Source
Arch Linux	Vulnerable Issues
Alpine Linux	secdb
Amazon Linux 1	Amazon Linux Security Center
Amazon Linux 2	Amazon Linux Security Center
Debian	Security Bug Tracker
	OVAL
Ubuntu	Ubuntu CVE Tracker
RHEL/CentOS	OVAL
	Security Data
AlmaLinux	AlmaLinux Product Errata
Rocky Linux	Rocky Linux UpdateInfo
Oracle Linux	OVAL
CBL-Mariner	OVAL
OpenSUSE/SLES	CVRF
Photon OS	Photon Security Advisory

Programming Language

Language	Source	Commercial Use	Delay¹
PHP	PHP Security Advisories Database	✅	-
	GitHub Advisory Database (Composer)	✅	-
Python	GitHub Advisory Database (pip)	✅	-
	Open Source Vulnerabilities (PyPI)	✅	-
Ruby	Ruby Advisory Database	✅	-
	GitHub Advisory Database (RubyGems)	✅	-
Node.js	Ecosystem Security Working Group	✅	-
	GitHub Advisory Database (npm)	✅	-
Java	GitLab Advisories Community	✅	1 month
	GitHub Advisory Database (Maven)	✅	-
Go	GitLab Advisories Community	✅	1 month
	The Go Vulnerability Database	✅	-
Rust	Open Source Vulnerabilities (crates.io)	✅	-
.NET	GitHub Advisory Database (NuGet)	✅	-

Others

Name	Source
National Vulnerability Database	NVD

Data source selection

Trivy only consumes security advisories from the sources listed in the following tables.

As for packages installed from OS package managers (dpkg, yum, apk, etc.), Trivy uses the advisory database from the appropriate OS vendor.

For example: for a python package installed from yum (Amazon linux), Trivy will only get advisories from ALAS. But for a python package installed from another source (e.g. pip), Trivy will get advisories from the GitLab and GitHub databases.

This advisory selection is essential to avoid getting false positives because OS vendors usually backport upstream fixes, and the fixed version can be different from the upstream fixed version. The severity is from the selected data source. If the data source does not provide severity, it falls back to NVD, and if NVD does not have severity, it will be UNKNOWN.

Ari-Gapped Environment

Trivy can be used in air-gapped environments. Note that an allowlist is here.

ghcr.io
pkg-containers.githubusercontent.com

Air-Gapped Environment for Vulnerabilities

Download the vulnerability database

At first, you need to download the vulnerability database for use in air-gapped environments. Please follow oras installation instruction.

Download db.tar.gz:

$ oras pull ghcr.io/aquasecurity/trivy-db:2 -a

Transfer the DB file into the air-gapped environment

The way of transfer depends on the environment.


$ rsync -av -e ssh /path/to/db.tar.gz [user]@[host]:dst

Put the DB file in Trivy’s cache directory

You have to know where to put the DB file. The following command shows the default cache directory.


$ ssh user@host
$ trivy -h | grep cache
   --cache-dir value  cache directory (default: "/home/myuser/.cache/trivy") [$TRIVY_CACHE_DIR]

Put the DB file in the cache directory + /db.


$ mkdir -p /home/myuser/.cache/trivy/db
$ cd /home/myuser/.cache/trivy/db
$ tar xvf /path/to/db.tar.gz -C /home/myuser/.cache/trivy/db
x trivy.db
x metadata.json
$ rm /path/to/db.tar.gz

In an air-gapped environment, it is your responsibility to update the Trivy database on a regular basis so that the scanner can detect recently-identified vulnerabilities.

Run Trivy with –skip-update and –offline-scan option

In an air-gapped environment, specify –skip-update so that Trivy doesn’t attempt to download the latest database file. In addition, if you want to scan Java dependencies such as JAR and pom.xml, you need to specify –offline-scan since Trivy tries to issue API requests for scanning Java applications by default.


$ trivy image --skip-update --offline-scan alpine:3.12

Air-Gapped Environment for misconfigurations

No special measures are required to detect misconfigurations in an air-gapped environment.

Run Trivy with –skip-policy-update option

In an air-gapped environment, specify –skip-policy-update so that Trivy doesn’t attempt to download the latest misconfiguration policies.

$ trivy conf --skip-policy-update /path/to/conf

Exceptions / Custom Policies

Exceptions let you specify cases where you allow policy violations. Trivy supports two types of exceptions. Example:


package user.kubernetes.ID100

__rego_metadata := {
    "id": "ID100",
    "title": "Deployment not allowed",
    "severity": "HIGH",
    "type": "Kubernetes Custom Check",
}

deny_deployment[msg] {
    input.kind == "Deployment"
    msg = sprintf("Found deployment '%s' but deployments are not allowed", [name])
}

exception[rules] {
    input.kind == "Deployment"
    input.metadata.name == "allow-deployment"

    rules := ["deployment"]
}

Custom Polcies

You can write custom policies in Rego. Once you finish writing custom policies, you can pass the directory where those policies are stored with –policy option.

trivy conf --policy /path/to/custom_policies --namespaces user /path/to/config_dir

File formats

File format	File pattern
JSON	`*.json`
YAML	`.yaml` and `.yml`
Dockerfile	`Dockerfile`, `Dockerfile.`, and `.Dockerfile`
Containerfile	`Containerfile`, `Containerfile.`, and `.Containerfile`
Terraform	`.tf` and `.tf.json`

Example:


package user.kubernetes.ID001

__rego_metadata__ := {
    "id": "ID001",
    "title": "Deployment not allowed",
    "severity": "LOW",
    "type": "Custom Kubernetes Check",
    "description": "Deployments are not allowed because of some reasons.",
}

__rego_input__ := {
    "selector": [
        {"type": "kubernetes"},
    ],
}

deny[msg] {
    input.kind == "Deployment"
    msg = sprintf("Found deployment '%s' but deployments are not allowed", [input.metadata.name])
}

Pipeline

Jenkins Pipeline

We will be using Jenkins as our main orchestrator. Created my own here: https://github.com/tamalerhino/chubby-unicorn/blob/main/Jenkinsfile


pipeline {
  agent any
  options {
    buildDiscarder(logRotator(numToKeepStr: '5'))
  }
  stages {
    stage('Build') {
      steps {
        sh 'docker build -t "${IMAGENAME}" .'
      }
    }
    stage('Scan') {
      steps {
        sh 'trivy image --exit-code 1 --severity MEDIUM,HIGH,CRITICAL "${IMAGENAME}"'
      }
    }

    stage('Create SBOM') {
      steps {
        sh 'trivy --output "${IMAGENAME}".json sbom "${IMAGENAME}"'
      }
    }
    stage('Upload Artifacts') {
      steps {
        sh 'docker login "${CONTAINER-REPO-URL}" -u="${CONTAINER-REPO-USERNAME}" -p="${CONTAINER-REPO-PASSWORD]"'
        sh 'docker tag "${IMAGENAME}" "${CONTAINERPROJECT}"/"${IMAGENAME}"'
        sh 'docker push "${CONTAINER-REPO-URL}"/"${CONTAINERPROJECT}"/"${IMAGENAME}"'
      }
       steps {
        sh 'curl -u "${USERNAME}":"${PASSWORD}" -X PUT  "${ARTIFACTORY-RUL}/"${CONTAINERPROJECT}"/"${IMAGENAME}".json" -T "${IMAGENAME}".json'
      }
    }
  }
}

Intentional delay between vulnerability disclosure and registration in the DB ↩
