At the end of the day, all a container is an isolated service with its dependencies, this document will go over how to create a container from scratch, using nothing but the built-in Linux kernel modules.
How?
As mentioned before, a container is nothing more than an isolated service running on the linux Kernel. How it does this is by using kernel level modules known as namespaces,cgroups and something called capabilities.
For a deeper explanation of containers,namespaces,cgroups etc see my blog on Namespaces
Prereqs
You will need some linux folders and structures, there are two ways to go about this.
- Using a Docker image, or rather exporting a Docker image.
- Downloading a basic filesystem or creating it from scratch.(checkout my other blog on creating debian distro from scratch “Bootstrapping Debian As a Container Image”)
Option 1 Creating The Container Image
On the machine a you have Docker installed.
Pull the alpine image
docker pull alpineRun the container
docker run -d --name alpine alpineFinally export the image to a tar file.
docker export --output=alpine.tar alpine
You will have a tar file that you can put anywhere to save for later.
Option 2 From Scratch
Follow my other blog “Bootstrapping Debian As a Container Image” to get a tar.gz of a basic debian filesystem.
Creating Container
With CHROOT
If you went the docker route just replace
debiantoalpineor whatever you named your tar file.
Get your tar image using wget or curl
Untar the image and take a look around, its just like any other linux distro.
Be adviced if you mess up the commands you will need to
sutorootbecause of permissions to delete stuff.
1
2
3
4
tamalerhino@localhost:~$ sudo mkdir debian
tamalerhino@localhost:~$ sudo tar -xzf debian.tar.gz -C debian
tamalerhino@localhost:~$ ls -la debian/
tamalerhino@localhost:~$ ls -al debian/etc/
We will use chroot (old school!) to restrict the view of the process.
This is what docker does when it does
docker run
1
2
3
4
5
6
tamalerhino@localhost:~$ sudo chroot debian /bin/bash
root@localhost:/# ls
bin boot dev etc home lib lib32 lib64 libx32 media mnt opt proc root run sbin srv sys tmp usr var
root@localhost:/# echo "Meow"
Meow
root@localhost:/# exit
Instead of a shell, we can run a command inside our
chroot.
Similar to dockers
docker exec -d <container> echo "Hello World"
1
2
3
tamalerhino@localhost:~$ sudo chroot debian echo "meow"
meow
tamalerhino@localhost:~$
Now of course if you try to install something using
aptyou will get an error since it does not have connectivity to the outside. Everything were running is from within our container.
However it’s not completely isolated yet!
You can check this by running top from outside the chroot container.
1
2
tamalerhino@localhost:~$ top &
[2] 1619
Then run the following commands to see that you can see the top command inside the chroot container.
1
2
tamalerhino@localhost:~$ sudo chroot debian /bin/bash
root@localhost:/# mount -t proc proc /proc
The
mount -t proc..commands are needed because when you runpsit is checking the/procfilesystem for the file representation of the running processes, and so we need to mount the/procglobal FS.
1
2
3
4
root@localhost:/# ps aux | grep top
1000 7725 0.0 0.0 10396 3240 ? T 22:18 0:00 top
root 7761 0.0 0.0 8172 668 ? S+ 22:19 0:00 grep top
root@localhost:/#
You should not be able to see that root process inside the container. Whats worse is you can actually kill that service from inside the container by running
1
root@localhost:/# pkill top
That defeats the purpouse of containers right?!
Isolation (namespaces)
OK now to isolate the whole thing using a syscall called unshare by using the CLI tool by the same name. This will create a namespace for our container to run in.
Below what we are doing is going into the debian directory, just like we would with chroot but now were giving ourselves specific namespaces to isolate the environment from the host environment and running bash as our process(the --fork flag is just saying we want to run bash as a child service of the unshare command.)
1
2
3
tamalerhino@localhost:~$ cd debian
tamalerhino@localhost:~/debian$ sudo unshare --mount --uts --fork bash
root@localhost:/home/tamalerhino/debian#
When we run the
unsharecommand and the namespaces eg--mount,--utswhat were saying is: create an envionrment and give us our own instances of these namespaces for example--mountwere saying we want our own mounts ie the ability to mount things only to our environement and not the host environment.
To test that youre in a container lets try changing the hostname
1
2
3
root@localhost:/home/tamalerhino/debian# hostname container
root@localhost:/home/tamalerhino/debian# exec bash
root@container:/home/tamalerhino/debian#
We have the ability to change the internal hostname of the container without changing the host’s hostname because we gave ourselves the
--utsnamespace earlier.
Open up a second terminal so you can check to see that your host system hostname has not changed!
1
2
3
# Second Terminal
tamalerhino@localhost:~$ hostname
localhost
Now to fix the issue with the fact that we can kill processes, if you were to run ps from inside the container right now this is what you would see:
1
2
3
4
5
6
7
root@container:/home/tamalerhino/debian# ps
PID TTY TIME CMD
10976 pts/3 00:00:00 sudo
10977 pts/3 00:00:00 unshare
10978 pts/3 00:00:00 bash
10989 pts/3 00:00:00 ps
root@container:/home/tamalerhino/debian#
We dont want that! The reason we are seeing that is because when we mounted everything we also added the global /proc directory to the container. Lets only mount our debian /proc directory to our namespace as well as the --pid, and --ipc namespaces.
1
2
3
4
5
6
root@container:/home/tamalerhino/debian# mount -t proc proc /proc
root@container:/home/tamalerhino/debian# ps
PID TTY TIME CMD
1 pts/3 00:00:00 bash
11 pts/3 00:00:00 ps
root@container:/home/tamalerhino/debian#
Now we can only see our processes.
Another way to do this is to add the
/procmountpoint to our originalunsharecommand ` sudo unshare –mount –uts –ipc –pid –mount-proc=/proc –fork bash`
Lets go ahead and take it one step further by telling the system that our root / directory is at the debian directory, we can do this by using pivot_root.
From the man page: “pivot_root() changes the root mount in the mount namespace of the calling process. More precisely, it moves the root mount to the directory put_old and makes new_root the new root mount.”
First we need to create a directory where our current root filesystem will be mounted.
Before you being create a file in your debian directory so you know that you are actually in your deban root directory later on like so
touch /home/tamalerhino/debian/DEEEEEEB
First we need to make a new directory close to our / root FS now.
1
root@container:/home/tamalerhino/debian# mkdir /newroot
Then we will bind mount our debian root fs to this newroot directory.
1
root@container:/home/tamalerhino/debian# mount --bind /home/tamalerhino/debian /newroot
Now we can go to the root FS and show that the newroot directory is there and our debian fs is mounted there.
1
2
3
4
5
6
7
8
root@container:/home/tamalerhino/debian# cd /
root@container:/# ls
bin dev home lib32 libx32 media newroot proc run snap swap.img tmp var
boot etc lib lib64 lost+found mnt opt root sbin srv sys usr
root@container:/# cd newroot/
root@container:/newroot# ls
DEEEEEEB boot etc lib lib64 media opt root sbin sys usr
bin dev home lib32 libx32 mnt proc run srv tmp var
Now comes the cool part we will use the command pivot_root to tell the system that our root FS is no longer the / but really now its /newroot and to treat it as such.
1
2
3
4
5
root@container:/newroot# pivot_root . .
root@container:/newroot# cd /
root@container:/# ls
DEEEEEEB boot etc lib lib64 media opt root sbin sys usr
bin dev home lib32 libx32 mnt proc run srv tmp var
See! now everytime we use / it points to our debian FS.
Now to do a little cleanup
This is a good stoping point, at this point we have a container that only sees its own processes, its own mounts and its own rootfs but we still need immutable volumes, networking and a little security. All this and much more to come in Part 2!
First run the following command since mount relies on this.
1
root@container:/# mount -t proc proc /proc
Now to see whats mounted. Only reason im running head is to get the first 10 lines otherwise it would be too much to render for the blog.
1
2
3
4
5
6
7
8
9
10
11
root@container:/# mount | head
/dev/mapper/ubuntu--vg-ubuntu--lv on / type ext4 (rw,relatime)
udev on /dev type devtmpfs (rw,nosuid,relatime,size=1936540k,nr_inodes=484135,mode=755,inode64)
devpts on /dev/pts type devpts (rw,nosuid,noexec,relatime,gid=5,mode=620,ptmxmode=000)
tmpfs on /dev/shm type tmpfs (rw,nosuid,nodev,inode64)
mqueue on /dev/mqueue type mqueue (rw,nosuid,nodev,noexec,relatime)
hugetlbfs on /dev/hugepages type hugetlbfs (rw,relatime,pagesize=2M)
tmpfs on /run type tmpfs (rw,nosuid,nodev,noexec,relatime,size=398444k,mode=755,inode64)
tmpfs on /run/lock type tmpfs (rw,nosuid,nodev,noexec,relatime,size=5120k,inode64)
none on /run/credentials/systemd-sysusers.service type ramfs (ro,nosuid,nodev,noexec,relatime,mode=700)
tmpfs on /run/snapd/ns type tmpfs (rw,nosuid,nodev,noexec,relatime,size=398444k,mode=755,inode64)
Go ahead and unmount everything
1
2
3
root@container:/# umount -a
umount: /: target is busy.
...
If you get errors like the one above saying something is busy just run
umount -l <the mount thats busy>in my caseumount -l /
Now when we run mount we see we get a nice little isolated container mounts.
1
2
3
4
root@container:/# mount
/dev/mapper/ubuntu--vg-ubuntu--lv on / type ext4 (rw,relatime)
proc on /proc type proc (rw,relatime)
proc on /proc type proc (rw,relatime)
